DA700 is certified to 80 PLUS Bronze, achieving up to 85% electrical efficiency, lowering heat generation and reducing operational costs. Integrated Active PFC + PWM Combo Controller boost exchange efficiency to achieve a PFC of higher than 99%. Outstanding and stable performance makes this PSU a leading choice for a wide range of applications.
80 PLUS BRONZE
80 PLUS Bronze certified, providing a high energy efficiency performance of up to 85%.
Silent, High Performance Fan
120 mm silent fan with temperature control that provides an incredible performance-to-noise ratio.
Longer Cable Design
Longer cable design for enhancing cable management.
Specifications
| Type | ATX 12V V2.4 |
| Certifications | 80PLUS Bronze |
| Dimensions (W x L x H) | 150×140×86 mm |
| Output Capacity | 700W |
| Input Voltage | 100~240V |
| Input Current | 10A |
| Input Frequency Range | 47~63Hz |
| Fan Size | 120mm Silent Fan |
| PFC | Active PFC (>0.99) |
| Power Good Signal | 100-500ms |
| Hold Up Time | >16ms |
| Efficiency | 85% Under Typical Load |
| Protection | OVP / UVP / SCP / OPP |
| Operation Temperature | 0~40°C |
| Regulatory | CE / FCC / CCC / CB / EAC |
| MTBF | 100,000 Hours |
